# mnist CNN分类实例
import tensorflow as tf
import numpy as np
from tqdm import tqdm
import matplotlib.pyplot as plt
# style设置
from matplotlib import style
from IPython import display
style.use('ggplot')
np.random.seed(42)
%matplotlib inline
data = np.load("./data/mnist.npz")
x_train,y_train,x_test,y_test = data['x_train'],data['y_train'],data["x_test"],data['y_test']
# 数据规整
x_train = x_train.reshape(-1,28,28,1) / 255 - 0.5
x_test = x_test.reshape(-1,28,28,1) / 255 - 0.5
# 这个能生成一个OneHot的10维向量，作为Y_train的一行，这样Y_train就有60000行OneHot作为输出
y_train = (np.arange(10) == y_train[:, None]).astype(int) # 整理输出
y_test = (np.arange(10) == y_test[:, None]).astype(int)
batch_size = 8 # 使用MBGD算法，设定batch_size为8
# batchsize的获取
def generatebatch(X,Y,n_examples, batch_size):
for batch_i in range(n_examples // batch_size):
start = batch_i*batch_size
end = start + batch_size
batch_xs = X[start:end]
batch_ys = Y[start:end]
yield batch_xs, batch_ys # 生成每一个batch
def model_cnn_0(tf_X):
print("cnn1")
# 第一卷积层+激活层
conv_filter_w1 = tf.Variable(tf.random_normal([3, 3, 1, 10]))
conv_filter_b1 = tf.Variable(tf.random_normal([10]))
relu_feature_maps1 = tf.nn.relu(tf.nn.conv2d(tf_X, conv_filter_w1,strides=[1, 1, 1, 1], padding='SAME') + conv_filter_b1)
print(relu_feature_maps1)
# 池化层
max_pool1 = tf.nn.max_pool(relu_feature_maps1,ksize=[1,3,3,1],strides=[1,2,2,1],padding='SAME')
print(max_pool1)
# 第二卷积层
conv_filter_w2 = tf.Variable(tf.random_normal([3, 3, 10, 5]))
conv_filter_b2 = tf.Variable(tf.random_normal([5]))
conv_out2 = tf.nn.conv2d(relu_feature_maps1, conv_filter_w2,strides=[1, 2, 2, 1], padding='SAME') + conv_filter_b2
# BN归一化层+激活层
batch_mean, batch_var = tf.nn.moments(conv_out2, [0, 1, 2], keep_dims=True)
shift = tf.Variable(tf.zeros([5]))
scale = tf.Variable(tf.ones([5]))
epsilon = 1e-3
BN_out = tf.nn.batch_normalization(conv_out2, batch_mean, batch_var, shift, scale, epsilon)
relu_BN_maps2 = tf.nn.relu(BN_out)
# 池化层
max_pool2 = tf.nn.max_pool(relu_BN_maps2,ksize=[1,3,3,1],strides=[1,2,2,1],padding='SAME')
print(max_pool2)
# 将特征图进行展开
max_pool2_flat = tf.reshape(max_pool2, [-1, 7*7*5])
# 全连接层
fc_w1 = tf.Variable(tf.random_normal([7*7*5,50]))
fc_b1 = tf.Variable(tf.random_normal([50]))
fc_out1 = tf.nn.relu(tf.matmul(max_pool2_flat, fc_w1) + fc_b1)
# 输出层
out_w1 = tf.Variable(tf.random_normal([50,10]))
out_b1 = tf.Variable(tf.random_normal([10]))
pred = tf.nn.softmax(tf.matmul(fc_out1,out_w1)+out_b1)
return pred
def model_cnn_1(x):
print("cnn2")
#conv2
#layers.conv2d parameters
#inputs 输入，是一个张量
#filters 卷积核个数，也就是卷积层的厚度
#kernel_size 卷积核的尺寸
#strides: 扫描步长
#padding: 边边补0 valid不需要补0，same需要补0，为了保证输入输出的尺寸一致,补多少不需要知道
#activation: 激活函数
cn1 = tf.layers.conv2d(inputs=x,filters=10,kernel_size=(3,3),strides=1,padding="same",activation=tf.nn.relu)
print(cn1)
#tf.layers.max_pooling2d
#inputs 输入，张量必须要有四个维度
#pool_size: 过滤器的尺寸
pool1 = tf.layers.max_pooling2d(inputs=cn1,pool_size=(3,3),strides=2,padding="same")
print(pool1)
#conv2
cn2 = tf.layers.conv2d(inputs=pool1,filters=5,kernel_size=3,strides=1,padding="same",activation=tf.nn.relu)
print(cn2)
# bn归一化层
batch_mean, batch_var = tf.nn.moments(cn2, [0, 1, 2], keep_dims=True)
shift = tf.Variable(tf.zeros([5]))
scale = tf.Variable(tf.ones([5]))
epsilon = 1e-3
BN_out = tf.nn.batch_normalization(cn2, batch_mean, batch_var, shift, scale, epsilon)
relu_BN_maps2 = tf.nn.relu(BN_out)
#pool2 2*2
pool2 = tf.layers.max_pooling2d(inputs=relu_BN_maps2,pool_size=3,strides=2,padding="same")
print(pool2)
#flat(平坦化)
flat = tf.reshape(pool2,[-1,7*7*5])
dense = tf.layers.dense(inputs=flat,units=50,activation=tf.nn.relu)
#输出层，不用激活函数（本质就是一个全连接层）
out = tf.layers.dense(inputs = dense,units=10,activation=tf.nn.softmax)
return out
tf.reset_default_graph()
# 输入层
tf_X = tf.placeholder(tf.float32,[None,28,28,1])
tf_Y = tf.placeholder(tf.float32,[None,10])
# model的输出
# 第一种cnn模型
out = model_cnn_0(tf_X)
# 第二种cnn模型
# out = model_cnn_1(tf_X)
# loss
loss = -tf.reduce_mean(tf_Y*tf.log(tf.clip_by_value(out,1e-11,1.0)))
# 优化
train_step = tf.train.AdamOptimizer(1e-3).minimize(loss)
# 计算准确率
y_pred = tf.arg_max(out,1)
bool_pred = tf.equal(tf.arg_max(tf_Y,1),y_pred)
accuracy = tf.reduce_mean(tf.cast(bool_pred,tf.float32)) # 准确率
num_epochs = 100
accs = []
with tf.Session() as sess:
sess.run(tf.global_variables_initializer())
for epoch in range(num_epochs): # 迭代1000个周期
for batch_xs,batch_ys in generatebatch(x_train,y_train,y_train.shape[0],batch_size): # 每个周期进行MBGD算法
sess.run(train_step,feed_dict={tf_X:batch_xs,tf_Y:batch_ys})
if(epoch % 10 == 0):
res = sess.run(accuracy,feed_dict={tf_X:x_test,tf_Y:y_test})
accs.append(res)
print(epoch,res)
|
